⇒Detailed specifications
Model number | Power | Size (mm) | IP | Luminous flux |
KEOU -FL37- 50W | 50W | 190x220x45mm | 66 | 5000lm |
KEOU -FL37-100W | 100W | 220x260x55mm | 66 | 10000lm |
KEOU -FL37-200W | 200W | 270x310x60mm | 66 | 20000lm |
KEOU -FL37-300W | 300W | 320x360x65mm | 66 | 30000lm |
KEOU -FL37-400W | 400W | 360x400x70mm | 66 | 40000lm |
⇒Product details
Quadruple protection + premium materials for maximum durability: IP66 dustproof and waterproof + explosion-proof + lightning protection, die-cast aluminum shell for fast heat dissipation, textured glass for softening and anti-glare, metal waterproof cable design, compression and impact resistant, suitable for complex outdoor environments, and extended service life. |  |
 | High-efficiency light source + safe driver for safer lighting: 2835 high-quality LED beads (luminous efficacy 90lm/W) provide uniform and sufficient light; non-isolated wide voltage driver with overcurrent and temperature control protection, PF0.95 energy saving, 4KV surge protection, and guaranteed electrical safety. |
Flexible installation + blind spot lighting, suitable for multiple scenarios: 180° rotating installation, adjustable bracket, achieving blind spot lighting, easy installation, suitable for various outdoor scenarios such as campuses, roads, squares, etc. |  |
⇒How to install and use flood lights?
Wall- mounted installation | Angle- adjustable installation | Multi- functional adapter installation (suspension/ base support) |
Cost-saving: No additional scaffolding is required, saving space and construction costs. Flexible layout: Not limited by poles, can be installed at fixed points as needed. Easy to install: Simple accessories, just drill a hole and install, no high-altitude equipment required. | Light control accuracy: Multi-angle rotation adjustment for precise matching of directional lighting. High stability: Damped pivot structure, no deviation after adjustment, excellent wind resistance. Easy to maintain: Simple operation, no professional tools required for later adjustments. | Wide range of applications: compatible with both hanging and base support, suitable for high ceilings or flat layouts. Quick assembly and disassembly: The base support allows for rapid repositioning, suitable for temporary lighting scenarios. High adaptability: Adjustable hanging height, non-slip and wear-resistant base, suitable for various environments. |
⇒Application scenarios
 |  |  |
Tunnel entrance lighting: Multiple floodlights are installed at the top of both sides of the tunnel entrance section, which can quickly improve the visibility of the entrance area, effectively alleviate the visual gap for drivers entering and exiting the tunnel, and greatly improve driving safety. | Gas station lighting: Multiple floodlights are evenly installed under the roof of the gas station, which can effectively improve the brightness of nighttime lighting, eliminate blind spots, further enhance the safety of refueling operations, and improve overall operational efficiency. | Dock warehouse lighting: Multiple floodlights are installed on the top of the exterior wall of the dock warehouse to provide stable and bright lighting support, perfectly meeting the high-intensity lighting needs of the port's 24-hour uninterrupted operation and ensuring smooth nighttime operations. |
⇒Frequently Asked Questions (FAQ)
Q1. What environments can this IP66 floodlight adapt to?
A1: IP66 fully keeps out dust and strong water spray from all directions. With explosion-proof and lightning-proof design, it fits rainy, dusty and thunder-prone outdoor places like rural roads and squares for long-term safe use.
Q2. What’s the advantage of textured glass over ordinary glass?
A2: It softens light to avoid glare, protects eyes while keeping brightness, perfect for campuses and crowded plazas. It’s also more wear and impact resistant, and works better with the die-cast aluminum shell.
Q3. What functions do overcurrent protection and temperature control driver have?
A3:Overcurrent protection cuts power automatically with abnormal voltage or leakage to prevent burnout and safety risks. Temperature control adjusts power at high heat, protects LED beads, extends service life and ensures stable operation.
